Industrial Stretch Film Shredder PE / LDPE Plastic Films Grinder Large Capacity Customized Plastic Agricultural Film Shredder VFD Motor Blower Discharge System,HDPE OPP film

Features

Introduction
Contact Us
-+
ADD to Quote

Product Details

Product Introduction

Cutting and shredding machine  for leatherwear

Machine for chopping or grinding, cutting and shredding of PET and other plastic materials such as polypropylene PP, polyethylene PE, PES polyester, polystyrene PS, EVA, PVC, HIPS, big-bags, thermal blanket, plastic greenhouse, plastic agriculture raffia nets, ropes

We offers the cutting and shredding ROTATOR, a machine with working widths of 400-1500MM, with a variable cutting length (due to speed setting the feed belt) and a production capacity of up to 8000kg / hour (depending on the size of the shredded material).

The cutting process begins with the advance of the conveyor belt variable speed (adjustment of the cutting length is easily accomplished from the control panel). Subsequently, they pass the rotary cutting system, consisting of several blades. Finally, the extraction weaver totally evacuates all shredded matter.

Depending on the capacity of cutting or shredding or shaped material feeding for processing that is required.

Product parameters

Model

800F

1200F

1600F

2400F

Fixed Blade length

400mm

600mm

800mm

1200mm

Fixed Blade qty

2

2

2

2

Rotary blade qty

8

6

8

8

Cutting motor

7.5kw

18.5kw

22kw

22kw+22kw

Conveying motor

1.5kw

2.3kw

3kw

4kw

Input Conveyor belt size

1400*330mm

3000*520mm

3000*720mm

3000*1100mm

Sieve mesh adjustable range

3mm-50mm

3mm-140mm

3mm-200mm

3mm-200mm

work capacity (base on cut into 10 mm size)

100-150kg/h

250-350kg/h

450-650kg/h

800-1000kg/h

machine size (mm)

1350*1000*1100

1550*1450*1600

1550*1650*1700

2200*2043*1770

machine weight (kg)

800

1800

2300

3500

Applications

This fiber crusher is widely used in:

  • Textile waste recycling
  • Industrial material processing
  • Fiber product manufacturing
  • Waste management facilities

For optimal performance with your specific materials, we offer customized solutions to meet your production requirements. Contact our technical team to discuss your application needs.



FAQ

What are the main products/services of our company?

  • Our company is a factory of soft material crushers,It can crush various materials such as wool, palm silk, waste plastic bags, various fibers, greenhouse films, all kinds of used clothes, car interiors, shoes and socks, fishing nets, cord fabrics, etc.

  • We support customized services. Customers can customize machines according to their own needs.

  • Our company supports the service of trial operation with supplied materials. We can conduct a trial operation based on the materials you have. You can purchase our machines only after you are satisfied.


Payment terms

  • We support various forms of payment such as TT and letter of credit.

  • Pay a 30% deposit to start production and settle the balance before shipment.


What are our advantages?

  • We are a factory, with a price advantage and the ability to customize at the same time.

  • We have over 20 years of production experience and possess stable technology and excellent quality. Have independent patents.

  • We are a factory, with a price advantage and the ability to customize at the same time.

  • We have over twenty years of production experience and possess stable technology and excellent quality. Have independent patents.

  • We support your visit to our factory for on-site machine testing. Meanwhile, we can also provide video and written guidance to assist you in installing and using the machine. We also support sending our technical engineers overseas to assist you in debugging the machine.
