Industrial Waste Non-woven Fabric Shredder PP Woven Bags Sacks Shredder Polypropylene Bags Grinder Large Capacity Electricity Saving

Features

Introduction
Contact Us
-+
ADD to Quote

Product Details

Product Introduction


Cutting and shredding machine  for leatherwear

Machine for chopping or grinding, cutting and shredding of PET and other plastic materials such as polypropylene PP, polyethylene PE, PES polyester, polystyrene PS, EVA, PVC, HIPS, big-bags, thermal blanket, plastic greenhouse, plastic agriculture raffia nets, ropes

We offers the cutting and shredding ROTATOR, a machine with working widths of 400-1500MM, with a variable cutting length (due to speed setting the feed belt) and a production capacity of up to 8000kg / hour (depending on the size of the shredded material).

The cutting process begins with the advance of the conveyor belt variable speed (adjustment of the cutting length is easily accomplished from the control panel). Subsequently, they pass the rotary cutting system, consisting of several blades. Finally, the extraction weaver totally evacuates all shredded matter.

Depending on the capacity of cutting or shredding or shaped material feeding for processing that is required.

Product parameters


Model

800F

1200F

1600F

2400F

Fixed Blade length

400mm

600mm

800mm

1200mm

Fixed Blade qty

2

2

2

2

Rotary blade qty

8

6

8

8

Cutting motor

7.5kw

18.5kw

22kw

22kw+22kw

Conveying motor

1.5kw

2.3kw

3kw

4kw

Input Conveyor belt size

1400*330mm

3000*520mm

3000*720mm

3000*1100mm

Sieve mesh adjustable range

3mm-50mm

3mm-140mm

3mm-200mm

3mm-200mm

work capacity (base on cut into 10 mm size)

100-150kg/h

250-350kg/h

450-650kg/h

800-1000kg/h

machine size (mm)

1350*1000*1100

1550*1450*1600

1550*1650*1700

2200*2043*1770

machine weight (kg)

800

1800

2300

3500

Material comparison


Before


After


Note: The size of the crushing and the amount of work can be adjusted according to your actual needs

Delivery Time & payment term

  • Some machines are in stock. The production cycle of some small machines takes 2 to 3 weeks, and that of large machines takes 4 to 6 weeks

  • Pay a 30% deposit to start production and settle the balance before shipment. TT

  • We will arrange for a trial machine and test materials, and provide you with feedback on videos, pictures and samples of material cutting.
